SSR-6

Download Flyer & Specification Sheet

Easy to Program
- Simple conversational CNC software allows for easy input of data for grinding and dressing cycles.
Easy to Setup
- A “Teach” button makes it very easy to touch off the wheel to the part and/or dresser. Also setting grinding ram stroke. This “Teach” button process is not only easy but very efficient.
Constant Surface Speed
- To assure the highest degree of precision, the chuck spindle rotates at a variable speed with relationship of the wheel to the part. This Constant Surface Speed function also helps to assure a consistent surface finish across the whole part.
Automatic Dressing & Compensation
- Maximum efficiency requires dressing of the grinding wheel. The SSR-6 automates this process by automatically dressing the wheel when specified in process and compensates for the reduction in wheel diameter. Rough and finish dress conditions are controllable.
Thermally Stable Design
- To maintain accuracy throughout the workday, a machine must be designed with thermal distortion in mind. A thermally stable design will greatly minimize the effects of thermal distortion as the machine heats up throughout the day. All Amada grinders have been engineered to have exceptional thermal stability.
ECO-Friendly Design
- The SSR-6 is an “All Electric” machine and therefore does not require a hydraulic system.

Model	SSR-6
CNC Control Type	Fanuc Oi-TD w/ Amada Software
Magnetic Chuck Diameter	24” (600mm)
Grinding Wheel Size (OD x W x Bore)	14” x 1.5” x 5”
Grinding Spindle Power	10 HP
Machine Floor Space & Weight (With Coolant / Mist System & Maintenance Area)	6.8’ x 9.6’ and 5840 Lbs.

Specifications and machine design may change without notice at the sole discretion of Amada’s Engineering Department.
